نقد و بررسی تخصصی ام دی وی MIDEA مدل V5 X
| Model |
MV5-X252W/V2GN1 |
MV5-X280W/V2GN1 |
MV5-X335W/V2GN1 |
MV5-X400W/V2GN1 |
||
| Power supply | V/Ph/Hz |
380~415/3/50(60) |
||||
| Cooling | Capacity | kW |
25.2 |
28.0 |
33.5 |
40.0 |
| RT |
7.2 |
8.0 |
9.5 |
11.4 |
||
| kBtu/h |
86.0 |
95.5 |
114.3 |
136.5 |
||
| kcal/h |
21,672 |
24,080 |
28,810 |
34,400 |
||
| Power input | kW |
5.79 |
7.02 |
8.71 |
10.81 |
|
| EER | kW/kW |
4.35 |
3.99 |
3.85 |
3.7 |
|
| Heating mode | Capacity | kW |
27.0 |
31.5 |
37.5 |
45.0 |
| RT |
7.7 |
9.0 |
10.7 |
12.8 |
||
| kBtu/h |
92.1 |
107.5 |
128.0 |
153.5 |
||
| kcal/h |
23,220 |
27,090 |
32,250 |
38,700 |
||
| Power input | kW |
5.79 |
7.19 |
8.82 |
10.98 |
|
| COP | kW/kW |
4.66 |
4.38 |
4.25 |
4.10 |
|
| Connectable indoor unit | Total capacity | % |
50-130 |
|||
| Max. quantity |
13 |
16 |
20 |
23 |
||
| Sound pressure level | dB(A) |
57 |
57 |
58 |
60 |
|
| Pipe connections |
Liquid pipe | in.(mm) |
Φ3/8(Φ9.53) |
Φ3/8(Φ9.53) |
Φ1/2(Φ12.7) |
Φ1/2(Φ12.7) |
| Gas pipe | in.(mm) |
Φ7/8(Φ22.2) |
Φ7/8(Φ22.2) |
Φ1(Φ25.4) |
Φ1(Φ25.4) |
|
| Oil balance pipe | in.(mm) |
Φ1/4(Φ6) |
||||
| Fan motor | Type |
Axial propeller |
||||
| Quantity |
1 |
1 |
1 |
2 |
||
| Air flow rate | m3/h |
12,000 |
12,000 |
12,000 |
14,000 |
|
| CFM |
7,060 |
7,060 |
7,060 |
8,240 |
||
| Motor output | W |
465 |
465 |
465 |
290+230 |
|
| ESP | in.WG(Pa) |
0-0.08(0-20)(default) |
||||
| in.WG(Pa) |
0.08-0.24(20-60)(customized) |
|||||
| DC inverter compressor | Quantity |
1 |
1 |
1 |
2 |
|
| Capacity | kW |
31.59 |
31.59 |
23.25 |
13.8×2 |
|
| kBtu/h |
107.8 |
107.8 |
79.3 |
47.1×2 |
||
| Crankcase heater | W |
27.6×2 |
27.6×2 |
27.6×2 |
27.6×4 |
|
| Refrigerant | Type |
R410A |
||||
| Factory charging | Ibs.(kg) |
20(9) |
20(9) |
24(11) |
29(13) |
|
| Design pressure (High/Low) | MPa |
4.4/2.6 |
||||
| PSI |
640/380 |
|||||
| Net dimension (W×H×D) | inch |
39×64-3/8×31-1/8 |
52-3/4×64-3/8×31-1/8 |
|||
| mm |
990×1635×790 |
1340×1635×790 |
||||
| Packing size (W×H×D) | inch |
41-1/2×71-1/16×33-5/8 |
55-3/8×71-1/16×33-5/8 |
|||
| mm |
1055×1805×855 |
1405×1805×855 |
||||
| Net weight | lbs.(kg) |
483(219) |
483(219) |
523(237) |
655(297) |
|
| Gross weight | Ibs.(kg) |
516(234) |
516(234) |
556(252) |
695(315) |
|
| Operating temperature range | Cooling | °F(°C) |
23~118.4(-5~48) |
|||
| Heating | °F(°C) |
-4~75.2(-20~24) |
||||
| Model |
MV5-X450W/V2GN1 |
MV5-X500W/V2GN1 |
MV5-X560W/V2GN1 |
MV5-X615W/V2GN1 |
||
| Power supply | V/Ph/Hz |
380~415/3/50(60) |
||||
| Cooling | Capacity | kW |
45.0 |
50.0 |
56.0 |
61.5 |
| RT |
12.8 |
14.3 |
16.0 |
17.6 |
||
| kBtu/h |
153.5 |
170.6 |
191.1 |
209.8 |
||
| kcal/h |
38,700 |
43,000 |
48,160 |
52,890 |
||
| Power input | kW |
12.83 |
14.47 |
16.67 |
18.77 |
|
| EER | kW/kW |
3.51 |
3.46 |
3.36 |
3.28 |
|
| Heating | Capacity | kW |
50.0 |
56.0 |
63.0 |
69.0 |
| RT |
14.2 |
16.0 |
18.0 |
19.7 |
||
| kBtu/h |
170.6 |
191.1 |
214.9 |
235.4 |
||
| kcal/h |
43,000 |
48,160 |
54,180 |
59,340 |
||
| Power input | kW |
12.47 |
14.15 |
15.98 |
17.86 |
|
| COP | kW/kW |
4.01 |
3.96 |
3.94 |
3.86 |
|
| Connectable indoor unit | Total capacity | % |
50-130 |
|||
| Max. quantity |
26 |
29 |
33 |
36 |
||
| Sound pressure level | dB(A) |
60 |
61 |
61 |
61 |
|
| Pipe connections |
Liquid pipe | in.(mm) |
Φ1/2(Φ12.7) |
Ф5/8(Ф15.9) |
Ф5/8(Ф15.9) |
Ф5/8(Ф15.9) |
| Gas pipe | in.(mm) |
Ф1-1/8(Ф28.6) |
Ф1-1/8(Ф28.6) |
Ф1-1/8(Ф28.6) |
Ф1-1/8(Ф28.6) |
|
| Oil balance pipe | in.(mm) |
Φ1/4(Φ6) |
||||
| Fan motor | Type |
Axial propeller |
||||
| Quantity |
2 |
|||||
| Air flow rate | m3/h |
14,000 |
16,000 |
16,000 |
16,000 |
|
| CFM |
8,240 |
9,410 |
9,410 |
9,410 |
||
| Motor output | W |
290+230 |
420+350 |
440+350 |
440+350 |
|
| ESP | in.WG(Pa) |
0-0.08(0-20)(default) |
||||
| in.WG(Pa) |
0.08-0.24(20-60)(customized) |
|||||
| DC inverter compressor | Quantity |
2 |
||||
| Capacity | kW |
13.8×2 |
11.8+23.25 |
23.25×2 |
23.25×2 |
|
| kBtu/h |
47.1×2 |
40.3+79.3 |
79.3×2 |
79.3×2 |
||
| Crankcase heater | W |
27.6×4 |
||||
| Refrigerant | Type |
R410A |
||||
| Factory charging | Ibs.(kg) |
29(13) |
29(13) |
35(16) |
35(16) |
|
| Design pressure (High/Low) | MPa |
4.4/2.6 |
||||
| PSI |
640/380 |
|||||
| Net dimension (W×H×D) | inch |
52-3/4×64-3/8×31-1/8 |
||||
| mm |
1340×1635×790 |
|||||
| Packing size (W×H×D) | inch |
55-3/8×71-1/16×33-5/8 |
||||
| mm |
1405×1805×855 |
|||||
| Net weight | lbs.(kg) |
655(297) |
673(305) |
750(340) |
750(340) |
|
| Gross weight | Ibs.(kg) |
695(315) |
712(323) |
790(358) |
790(358) |
|
| Operating temperature range | Cooling | °F(°C) |
23~118.4(-5~48) |
|||
| Heating | °F(°C) |
-4~75.2(-20~24) |
||||
